प्रश्न
How does the heat H produced by a current passing through a fixed resistance wire depend on magnitude of current I?
Advertisements
उत्तर
Heat produced by a current passing through a wire with a fixed resistance depends on the square of current, I.
Heat, H = I2 x R x t
