प्रश्न
In the following diagram showing dispersion of white light by a glass prism, the colours 'P' and 'Q’ respectively are:
विकल्प
Red and Violet
Violet and Red
Red and Blue
Orange and Green
Advertisements
उत्तर
Violet and Red
Explanation:
The splitting of white light into its constituent colours is known as light dispersion. The spectrum is the band of seven colours produced by splitting white light. All of the constituent colours of white light have the same velocity in vacuum, but their velocity changes when they pass through a transparent 'medium' like a glass prism. Different colours are diverted by different angles on the prism's initial face. Violet's minimum speed is deviated by the maximum angle, whereas red's maximum speed is distorted by the minimum angle. As a result, the letters 'P' and 'Q' are violet and crimson, respectively.
संबंधित प्रश्न
Draw a ray diagram to explain the term angle of deviation.
Study the following ray diagram:
In this diagram, the angle of incidence, the angle of emergence and the angle of deviation respectively have been represented by
(A) y, p, z
(B) x, q, z
(C) p, y, z
(D) p, z, y
Complete the ray diagram given below to show the nature of light produced on the screen.
In an experiment to trace the path of a ray of light through a triangular glass prism, a student would observe that the emergent ray
(a) is parallel to the incident ray.
(b) is along the same direction of incident ray.
(c) gets deviated and bends towards the thinner part of the prism.
(d) gets deviated and bends towards the thicker part (base) of the prism.
When we place a glass prism in the path of a narrow beam of white light a spectrum is obtained. What happens when a second identical prism is placed in an inverted position with respect to the first prism? Draw a labelled ray diagram to illustrate it.
Complete the ray diagram given below to show the nature of light produced on the screen.
The completed ray diagram is as shown below:
Observe the given figure and write appropriate phenomenon of light in the box.
State True or False:
"Wavelength of red light is close to 700 nm.”
When sunlight passes through water droplets in the atmosphere it gets dispersed into its constituent colours forming a rainbow. A similar phenomenon is observed when white light passes through a prism.
Which colour will show the maximum angle of deviation and which colour will show the minimum angle of deviation?
